Technical Skills

PLC / SCADA Related

• Concept V2.5, Factorylink Configuration Explorer (V7.0, 7.2*, 7.5*)
• ProWorx32, Proworx NXT
• Tecnomatix Client Builder (V7.0, 7.2*, 7.5*)
• RS Logix 5, RS Logix 500, RS Logix 5000, RS View 32
• Factorytalk View SE, ME, Historian SE
• Panel Builder 32
• RS SoftLogix / Test Stand
• VersaPro
• PICS Pro
• GE iFix
• Wonderware Products
• Ignition by Inductive Automation SCADA Suite

* Attended Tecnomatix Factory Link Training classes

Hardware

• AB ControlLogix, CompactLogix, MicroLogix, SLC & PLC5 PLCs
• Modicon Quantum PLCs
• Prosoft Modbus Protocol Communication Modules
• GE MDS SD9 Ethernet Radio
• PQM-II Power Monitoring Modules
• Allen Bradley, Eaton VFD’s and Motor Starters

Operating Systems / Services

• MS DOS
• Windows 3.11, ’95, ’98, 2000, XP, NT 4.0, Vista, Windows 7 (32, 64 bit)

Other software

• Microsoft Office 2000 (Excel, Word, Access, Power point, Internet Explorer)
• MS Visio / Visual Basic
• Mozilla Firefox
• TOAD Oracle Application (Limited Experience)
• OSI PI Database configuration with Factorytalk Historian SE
• MSSQL 2005
• MS Reporting Services web based reporting query tool
• FactoryTalk Transaction Manager (interfaced with MSSQL 2005)
• Specter Instruments WIN-911 Autodialer Software

RSLogix 5000 Function Block Diagram Example
(opens new window)

RSLogix 5000 Structured Text Routine Example
(opens new window)

RSLogix 5000 Sequential Function Chart Example
(opens new window)

Device Function Block internal Ladder Logic Example
(opens new window)
